Gaskets

Products List

FGBK-23-G-140

Our Stainless Steel 316 Ring Type Joint (RTJ) Gaskets, designed to meet ASME B16.20 specifications, are crafted for optimal performance. With a size of 4 inches (DN100) and a Class 600 LB (PN100) rating, these gaskets are characterized by their oval shape and feature a Teflon Fluoropolymer coating. The blue color enhances visibility and distinguishes them for specific applications.

FGBK-23-G-138

Our Zinc Coated Oval Type Gaskets, designed in compliance with ASME B16.20 R Series (specifically R31), are produced using high-quality Soft Iron material. These gaskets offer a maximum hardness of 90 HB, providing reliable sealing solutions for various industrial applications.

FGBK-23-G-136

Our ASME B16.20 Semi-Metallic Gasket is expertly manufactured for 5-inch applications with a Class 1500 LB rating. It features an AISI 304 Inner Ring, CS Outer Ring, and an AISI 304 Hoop filled with Flexible Graphite. Count on the reliability and performance of our gaskets for your industrial needs.

FGBK-23-G-134

Our CGI Type Spiral Wound Gasket, crafted in accordance with ASME B16.20 standards, is designed for 6-inch, Class 300 LB applications. Featuring an SS 316L Inner Ring, Carbon Steel Outer Ring, AISI 316L Hoop, and FG Filler, it provides reliable sealing for various industrial uses. Trust in the quality and performance of our gaskets for your applications.

FGBK-23-G-132

Our AISI 347 Stainless Steel Gasket, manufactured in accordance with ASME B16.20, is tailored for 2-inch, DN50, Class 300 LB, and PN50 specifications. Its oval shape makes it ideal for ASME B16.5 RTJ Flange applications. Trust in the quality and precision of our gaskets for your sealing needs.

FGBK-23-G-130

Our ASME B16.20 Metal Seal Ring, produced in China, is a reliable choice for RTJ flanges. With a size of 18 inches, R69 profile, and available in Class 300 LB and 600 LB, this seal ring is crafted from AISI 410 material with a maximum hardness of 170 HB. Its oval shape ensures effective sealing in demanding applications.

FGBK-23-G-128

Our AISI 316 Metal Gasket Ring, sourced from China, is designed for ASME B16.5 RTJ Flanges in high-pressure applications. With an oval shape, a diameter of 2 inches, and a Class 600 LB rating, this gasket ring is coated with Teflon fluoropolymer for enhanced performance in demanding environments.

FGBK-23-G-126

Our Dielectric Flange Gasket Kit, produced in China, is tailored for Class 300 LB applications. This 6-inch kit adheres to Type F specifications and includes a G10 sleeve, phenol carrier disc, and nitrile sealing for optimal performance. The package also contains G10 + ZPS washers, ensuring reliable sealing for your flange connections.

FGBK-23-G-126

Our G10 Flange Insulating Gasket, manufactured in China, is designed with precision for Class 600 LB applications. Featuring Version F, this 2-inch gasket employs PTFE sealing for reliable performance. The kit includes a G10 retainer and sleeve, along with G10 + ZPS washers. Trust the quality of our insulation gasket for your flange sealing needs.
